Studer OnAir 3000 User Manual

OnAir 3000 Digital Mixing Console
9-22 Networking
Document generated: 10.10.14
SW V6.0
9.4.2.4 Livewire/OnAir audio clocking scheme
In addition to the network design itself, it is also important to take the right
approach for the audio clocking of the Livewire/OnAir system. Here are three
basic clocking schemes :
Single OnAir
Livewire Audio
Network
Wordclock
AoIP
SCoreLive
Ext. Wordclock Input
Wordclock Output
Multiple OnAir
Ethernet Switch
SCoreLive
Ext. Wordclock Input
Wordclock Output
SCoreLive
Ext. Wordclock Input
Wordclock Output
D21m Livewire card
set to be Clock Master
Wordclock
AoIP
Multiple OnAir with LW Node
Axia Livewire xNode
Ethernet Switch
D21 Mastersync
SCoreLive
Ext. Wordclock Input
SCoreLive
Ext. Wordclock Input
Axia Livewire xNode
set to be Clock Master
(Prio=7)
Wordclock
AoIP
