Studer OnAir 3000 User Manual

OnAir 3000 Digital Mixing Console
2-6 General
Document generated: 10.10.14
SW V6.0
2.3 Technical Specifications Subject to change without notice
General Level specs, digital, in dB
FS
dB, referenced to full scale (dB
FS
, dB full scale)
Level specs, analog, in dBu 0 dB 0.775 Vrms
Sampling rate 48 kHz ±50 ppm (internally synchronized)
Headroom adjustable, 0 to 20 dB
Default setting 9 dB
Output level 15 dBu @ 0 dB
FS
All input faders set to their 0 dB position. External analog sources: source impedance
< 200 Ω. Frequency range: 20 Hz to 20 kHz, if not stated otherwise.
All input and output cards are standard Studer D21m cards. For detailed description
and specifications please refer to the respective D21m data sheets.
Microphone Inputs Sensitivity –60 dBu…26 dBu for 0 dB
FS
Gain setting in steps of 1 dB
Frequency response (30 Hz…20 kHz) –0.3 dB
High-pass filter (12 dB/octave) 75 Hz
Input impedance 1.8 kΩ
Insert level (for 0 dB
FS
) +15 dBu
Dynamics 107 dB
THD+N (30 Hz…20 kHz, –1 dB
FS
) –95 dB
FS
THD+N (1 kHz, –30 dB
FS
) –111 dB
FS
Equivalent input noise (R
i
200 Ω, max gain) –124 dBu
Crosstalk (1 kHz) –110 dB
Phantom power, switchable 48 V
Line Inputs Level (for full scale) 15 or 24 dBu fixed (jumper), or 7...26 dBu adjustable
Impedance min. 10 kΩ
Frequency response (20 Hz...20 kHz) –0.2 dB
THD+N (35 Hz…20 kHz, –1 dB
FS
, input level fixed) max. –97 dB
FS
THD+N (1 kHz, –30 dB
FS
, input level fixed) max. –111 dB
FS
Crosstalk (1 kHz) max. –110 dB
Digital Inputs/Outputs
Impedance 110
Ω
Output level (into 110 Ω) 5 V
Input Sampling rate with SFC 32…108 kHz
Analog Outputs Level (for full scale) 15 or 24 dBu fixed (jumper), or 7…26 dBu adjustable
Impedance 40 Ω
Min. load at +24 dBu 600 Ω
Frequency response (20 Hz…20 kHz) –0.2 dB
THD+N (20 Hz…20 kHz, –1 dB
FS
, input level fixed) max. –90 dB
FS
THD+N (1 kHz, –30 dB
FS
, input level fixed) max. –110 dB
FS
Crosstalk (1 kHz) max. –110 dB
FS
Equalizer 4-band parametric, each band sweepable 20 Hz…20 kHz: ±18 dB
Power Supply Voltage auto-ranging, 100 to 240 V, 50/60 Hz
Power consumption SCore, typical system 120 W
Power consumption desk, typical system 150 W
Weight OnAir 3000 fixed frame, 12 faders, with screens 42 kg
OnAir 3000 fixed frame, 18 faders, with screens 47 kg
Note Dependingontheapplication, the OnAir 3000canhave differentconfig
urations. For this reason the values mentioned above are applicable only to
atypicalconfiguration;inanindividualcase,thevaluesmaydiffer.

Studer OnAir 3000 Specifications

General

Brand	Studer
Model	OnAir 3000
Category	Music Mixer
Language	English
