OnAir 3000 Digital Mixing Console
Operation 5-97
Document generated: 10.10.14
SW V6.0
5.7.2 Saving Initial Snapshots
Manual Save Mode When touching either the Desk Settings - Save button on the Admin -
Config page of the user GUI or one of the Save ... buttons in the configura-
tion tool, the corresponding parameters are saved in the corresponding data
file(s).
AutoSave Mode Automatic saving of the initial operational (i.e., desk setting) snapshot can
be activated with the configuration tool (refer to chapter 6.5.26.1). If active,
writing a new data file is triggered no longer than 10 seconds after a desk
setting has been changed.
Note: AutoSave mode must be switched Off whenever initial snapshot files are
copied or moved manually.
5.7.3 Snapshot File Contents
5.7.3.1 Initial Snapshots
The initial snapshots contain all configuration parameters of the correspond-
ing sub-system (‘container’).
*.cfg Configuration Snapshot • allparametersoftheconfigurationtype,setbytheConfigTool(core,desk,
channel screen)
  • allI/Osharing-relevantparameterssetbytheConfigTool(core)
  • deskresourcedefinitionparameters(desk)
  • partialoutputroutingsnapshots.
.
*.ops Operational Snapshot • allsettingswithintheuserGUIandthedesksurface
  • thesameparametersasanaudiosnapshot(core)
  • thesameparametersastheinputroutingsnapshot(core)
  • thesameparametersastheoutputroutingsnapshot(core)
  • thesameparametersastheassignmentsnapshot(desk)
  • monitoringparameters,suchasCR,ST1..3source(core)
*.usr User Snapshot • alluser-relevantparameterssetbytheConfigTool(core)
  • allpolicies-relevantparameterssetbytheConfigTool(core)
  • alldepartment-relevantparameterssetbytheConfigTool(core).
*.key License key Snapshot This is the only file that belongs to the start-up configuration of the console
(initial snapshot), but is not handled by the snapshot extension.
  • alllicensekeysforoptionalsoftwarefunctions(core).
