Studer OnAir 3000 - Monitoring Source Selector Keys; N-X Mode; Rotary Assignment Function Keys; Talkback Destination Keys

A/B Desk Configuration 7-13
OnAir 3000 Digital Mixing Console
Document generated: 10.10.14
SW V6.0
7.4.7 Monitoring Source Selector Keys
Configuration Tool: Desk Common → Keys
The monitoring sources selectable either on the monitoring/talkback module
orwithinthemonitoringpageoftheUserGUIareconfiguredhereforeach
location (CR, ST1...3).
Note: Only signals related to the corresponding desk should be defined for a certain
location;e.g.AUX1mustnotbeaddedtotheMonSrcST1listifitisnotused
on the secondary desk.
7.4.8 Talkback Destination Keys
Configuration Tool: Desk Common → Keys
Talkback destinations, selectable on the monitoring/talkback module or within
theTBSPpageoftheUserGUI,areconfiguredhereforeachlocation(CR,
ST1..3).
Note: Only talkback destinations related to the corresponding desk should be defined
for a certain location; e.g. TB to PGM A must not be added to the TB ST1 list
if PGM A is not used on the secondary desk.
7.4.9 Rotary Assignment Function Keys
Configuration Tool: Desk Primary Desk → Fader Assign → Group X
Configuration Tool: Desk Primary Desk → Rotary Assign → Group Y
Configures the rotary assignment function keys for the fader and rotary assign-
ment modules, considering the desk resource definition.
Note: Only rotary functions related to the corresponding desk should be added to
thelist;e.g.Aux1mustnotbeaddedtothelistifAUX1isnotusedonthe
secondary desk.
  Thelabelsoftherotaryfunctionmaybechangedaswell;e.g.theAUX4
rotaryfunctionmayappearasAUX1onthesecondarydesk.
7.4.10 N–X Mode
Configuration Tool: Config → Masters
Since the secondary desk normally uses PGM B, the default initialization of
the N–X mode must be changed to PGM B for all N–X buses that are assigned
to the secondary desk.
