Directives and standards
EU directives
16
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
Product Type
Standard
 SPC5320.320
 SPC4320.320
 SPCP332.300
EN50131 Grade 2
Specific information in relation to EN50131 requirements can be found in the
following sections in this document.
EN50131 Requirement
SPC Installation & Configuration Manual
Operating temperature and humidity range
Technical data SPC4000 [➙ 31]
Technical data SPC5000 [➙ 32]
Technical data SPC6000 [➙ 35]
Weights and dimensions
Technical data SPC4000 [➙ 31]
Technical data SPC5000 [➙ 32]
Technical data SPC6000 [➙ 35]
Fixing details
Mounting system equipment [➙ 40]
Installation, commissioning and
maintenance instructions, including terminal
identifications
Mounting system equipment [➙ 40]
Controller hardware [➙ 66]
Type of interconnections (refer to 8.8);
Technical data SPC4000 [➙ 31]
Technical data SPC5000 [➙ 32]
Technical data SPC6000 [➙ 35]
Wiring the X-Bus Interface [➙ 72]
Details of methods of setting and unsetting
possible (see 11.7.1 to 11.7.3 and Tables 23
to 26);
User programming via the keypad
Areas – Setting/Unsetting [➙ 243]
Configuring a keyswitch expander [➙ 207]
Configuring a wireless fob [➙ 106]
Triggers [➙ 255]
Serviceable parts
Technical data SPC4000 [➙ 31]
Technical data SPC5000 [➙ 32]
Technical data SPC6000 [➙ 35]
Power supply requirement if no integrated
PS
See installation instructions for SPCP33x
and SPCP43x Expander PSUs.
Where PS is integrated, the information
required by EN 50131-6:2008, Clause 6
Technical data SPC4000 [➙ 31]
Technical data SPC5000 [➙ 32]
Technical data SPC6000 [➙ 35]
Maximum number of each type of ACE and
expansion device.
Wiring the X-Bus Interface [➙ 72]
Technical data SPC4000 [➙ 31]
Technical data SPC5000 [➙ 32]
Technical data SPC6000 [➙ 35]
Current consumption of the CIE and each
type of ACE and expansion device, with and
without an alarm condition.
See relevant installation instructions.
Maximum current rating of each electrical
output
Technical data SPC4000 [➙ 31]
Technical data SPC5000 [➙ 32]
Technical data SPC6000 [➙ 35]
Programmable functions provided
Engineer programming via the keypad
[➙ 110]
Engineer programming via the browser
[➙ 159]
