Engineer programming via the browser
Installation & Configuration Manual
Your system will not comply with EN standards if you enable a function key to set
the system without a valid PIN being required.
Select the area is to be controlled by the function key.
Select the function to be performed by this key in this area..
Select an area if the indicator module is located in a secure area.
There are 8 indicators / LEDs on the right and 8 indicators / LEDs on the left side.
The function that is indicated by this LED.
Select the colour and the state for every indicator if the selected function is ON.
Select the colour and the state for every indicator if the selected function is OFF.
Press this button to change the function for this indicator. The function can be
enabled or used for a system, area, zone or keyswitch.
Select if the alarms should be audible.
Select if entry / exit should be audible.
Select if keypress should be audible.
Select if indicator expander should be limited by calendar.
Select if indicator module should be limited by a mapping gate.
Select if indication module should be limited by a keyswitch.
Select if indicator module should be limited to a valid PIN entered on a keypad.
(see warning above)
Select if indicator module should not be activated until a valid card/fob is
presented to the built-in card reader.
Configuring a Keyswitch Expander
1. Select Settings > X-Bus > Expanders.
2. Click one of the keyswitch identifying parameters.
The following dialog is displayed.
