Xerox Phaser 790

10/00
7-5
Phaser 790/DocuColor 2006
Plug/Jack Locations
Wiring Data
Initial Issue
202 Feed Clutch (Bypass Tray) Figure 4
203 Empty Sensor Figure 4
204 Pitch Sensor Figure 4
205 Intermediate Connector Figure 4
206 Bypass Tray Guide Switch Figure 4
207 Bypass Tray Interlock Figure 2
208 Lift Motor Assembly Figure 4
209 Stack Height Sensor Figure 4
210 Lift Plate Sensor Figure 4
210 SCSI Connector Figure 17
211 Bypass Tray Intermediate Connector Figure 6
211 SCSI Connector Figure 17
212 Feeder PWB Figure 10
213 Feeder PWB Figure 10
214 Feeder PWB Figure 10
215 Feeder PWB Figure 10
216 Feeder PWB Figure 10
217 Feeder PWB Figure 10
218 Feeder PWB Figure 10
219 No Paper Sensor (Tray 2) Figure 12
J220 DADF to ICM Main PWB Connector Figure 14
P220 ICM Main PWB Connector for DADF Figure 17
220 No Paper Sensor (Tray 3) Figure 12
221 Low Paper Sensor (Tray 2) Figure 11
222 Low Paper Sensor (Tray 3) Figure 11
223 Feedout Sensor (Tray 2) Figure 12
224 Feedout Sensor (Tray 3) Figure 12
225 Nudger Solenoid Assembly (Tray 2) Figure 11
226 Nudger Solenoid Assembly (Tray 3) Figure 11
227 Turn Clutch Assembly (Tray 2) Figure 10
228 Turn Clutch Assembly (Tray 3) Figure 10
229 Takeaway Clutch Assembly (Tray 2) Figure 10
230 Takeaway Clutch Assembly (Tray 3) Figure 10
231 Low Paper Sensor (Tray 2) Figure 12
232 Low Paper Sensor (Tray 3) Figure 12
233 Feeder Drive Assembly (Tray 2) Figure 11
234 Feeder Drive Assembly (Tray 3) Figure 11
235 Size Switch Assembly (Tray 2) Figure 11
236 Size Switch Assembly (Tray 3) Figure 11
237 Feeder Right Cover Interlock 1 Figure 10
Table 1 Plug/Jack Location List
Plug/Jack
Number Location Figure Number
238 Feeder Right Cover Interlock 2 Figure 10
239 Feeder Motor Assembly Figure 10
240 Feeder Motor Assembly Figure 10
241 Intermediate Connector (Tray 2) Figure 10
242 Intermediate Connector (Tray 3) Figure 10
245 Rotary Motor PWB Figure 6
246 Rotary Motor PWB Figure 6
247 Rotary Motor PWB Figure 6
317 Control Panel Figure 3
320 Connects ICM Main PWB and Extension PWB Figure 17
602 I/F Connector for IOT Figure 17
603 I/F Connector for IOT Figure 17
709 Document Set LED Figure 14
711 Document Set Sensor Figure 14
712 ADF Registration Sensor Figure 14
713 ADF Nudger Home Sensor Figure 14
714 Feeder Cover Interlock Figure 14
716 IIT Figure 16
717 IIT Figure 16
718 ADF Exit Sensor Figure 14
718 IIT Figure 15
719 IIT Figure 16
719 Exit Tray Interlock Figure 14
721 Front Fuser Exit Sensor Figure 8
722 Rear Fuser Exit Sensor Figure 8
811 ADF Harness connection to Scanner Figure 14
812 ADF Drive Motor Figure 14
813 ADF Exit Motor Figure 14
814 ADF Control PWB Figure 14
815 ADF Control PWB Figure 14
816 ADF Control PWB Figure 14
CN1 IIT Figure 16
CN1 Motor Drive PWB Figure 6
CN2 IIT Figure 16
CN2 Paper Handling Motor Assembly Figure 7
E1 Commoning Connector Figure 8
F187-1 BCR Assembly Figure 5
F187-2 Developer Contact Plate Assembly Figure 1
F250 Connects Pressure Roll Heater and Heat Roll
Heater
Figure 8
Table 1 Plug/Jack Location List
Plug/Jack
Number Location Figure Number
