10/00
7-4
Phaser 790/DocuColor 2006
Plug/Jack Locations
Initial Issue
Wiring Data
83 Toner Box Sensor Figure 1
84 Intermediate Connector Figure 1
85 CRUM Assembly Figure 1
86 Erase Lamp Assembly Figure 1
87 Cartridge Sensor Figure 5
88 Waste Toner Sensor Figure 1
91 IIT LVPS Figure 15
J91 Fuser Intermediate Connector Figure 4
P91 Fuser Intermediate Connector Figure 2
93 Registration Sensor Figure 4
94 Registration Clutch Assembly Figure 4
95 Preregistration Clutch Assembly Figure 4
97 Intermediate Connector Figure 2
98 OHP Sensor Figure 4
100 BTR 2 Cam Sensor Figure 2
100 Connects ICM Main PWB and IIT LVPS Figure 17
101 Intermediate Connector Figure 2, Figure 7
102 Size Switch Assembly (Tray 1) Figure 7
103 Feed Solenoid (Tray 1) Figure 6
103 Feed Solenoid (Tray 1) Figure 2
104 Turn Clutch Figure 6
105 Environment Sensor Figure 2
106 Low Paper Sensor Figure 2
107 Tray No paper Sensor Figure 2
109 Turn Chute Interlock Figure 2
110 IIT Carriage Motor Figure 17
111 Fuser Fan 1 Figure 8
112 Exit Chute Fan Figure 8
116 Intermediate Connector Figure 1
117 Fuser In Sensor Figure 8
120 Connects ICM Main PWB and FLPS PWB Figure 17
121 ROS Assembly Figure 5
122 ROS Assembly Figure 5
123 ROS Assembly Figure 5
124 ROS Assembly Figure 5
125 ROS Assembly Figure 5
130 ICM Main PWB Figure 17
132 Intermediate Connector Figure 6
133 Sorter Intermediate Connector Figure 18
134 Intermediate Connector for Duplex Option Figure 7, Figure 9
Table 1 Plug/Jack Location List
Plug/Jack
Number Location Figure Number
139 Duplex Control PWB Figure 9
140 IIT Figure 16
140 Duplex Control PWB Figure 9
141 Duplex Control PWB Figure 9
142 Duplex Control PWB Figure 9
144 Duplex Control PWB Figure 9
145 Aligner Sensor Figure 13
146 Aligner Out Sensor Figure 13
147 Inverter Motor Figure 9
148 Duplex Nip Solenoid Figure 7
149 Aligner Drive Clutch Figure 13
150 Forward Clutch Figure 9
150 IIT Front Fan Figure 17
150A/B IIT Front Fan Intermediate Connector Figure 16
151 IIT Rear Fan Figure 17
151 Reverse Clutch Figure 9
152 Enter Clutch Figure 9
153 CAB Interlock Figure 9
154 Intermediate Connector Figure 13
155 Intermediate Connector Figure 13
158 Inverter Sensor Figure 9
159 Intermediate Connector Figure 13
160 Intermediate Connector Figure 13
161 Exit Harness Intermediate Connector Figure 8
163 Full Stack Sensor Figure 8
165 Top Exit Sensor Figure 8
166 Exit Chute Interlock Figure 8
167 Full Stack Sensor Figure 8
191 Right Front Cover Interlock Figure 1
192 Right Front Cover Interlock Figure 1
193 Right Front Cover Interlock Figure 1
194 Right Front Cover Interlock Figure 1
195 Intermediate Connector Figure 6
197 Intermediate Connector Figure 5
198 Left Front Cover Interlock Figure 5
199 Left Front Cover Interlock Figure 5
200 Connects ICM Main PWB and Control Panel PWB
(IIT)
Figure 17
201 Sorter Receiver Sensor Figure 18
201 Bypass Tray Intermediate Connector Figure 4
Table 1 Plug/Jack Location List
Plug/Jack
Number Location Figure Number
