YASKAWA GA700 Series

5.2 European Standards
228 YASKAWA SIEPC71061705H GA700 Series Technical Manual
■ Connect a Fuse to the Input Side (Primary Side)
The drive circuit protection must comply with IEC/EN 61800-5-1:2007 for protection against a short circuit in the
internal circuitry. Yaskawa recommends connecting semiconductor protection fuses on the input side for branch
circuit protection.
WARNING! Electrical Shock Hazard. After the drive blows a fuse or trips an RCM/RCD, do not immediately energize the drive
or operate peripheral devices. Wait for the time specified on the warning label at a minimum and make sure that all indicators
are OFF. Then check the wiring and peripheral device ratings to find the cause of the problem. If you do not know the cause of
the problem, contact Yaskawa before you energize the drive or peripheral devices. If you do not fix the problem before you
operate the drive or peripheral devices, it can cause serious injury or death.
Three-Phase 200 V Class
Table 5.2 Factory-Recommended Branch Circuit Protection (200 V Class)
Drive Model
Semiconductor Protection Fuse
Model
Manufacturer: EATON/Bussmann
2004 FWH-45B
2006 FWH-45B
2010 FWH-45B
2012 FWH-50B
2018 FWH-80B
2021 FWH-80B
2030 FWH-125B
2042 FWH-150B
2056 FWH-200B
2070 FWH-225A
2082
FWH-225A
FWH-250A
*1
Drive Model
Semiconductor Protection Fuse
Model
Manufacturer: EATON/Bussmann
2110
FWH-225A
FWH-250A
*1
2138
FWH-275A
FWH-300A
*1
2169
FWH-275A
FWH-350A
*1
2211
FWH-325A
FWH-450A
*1
2257 FWH-600A
2313 FWH-800A
2360 FWH-1000B
2415 FWH-1000B
*1 Yaskawa recommends a fuse with a large rated current for applications with repeated loads.
Three-Phase 400 V Class
Table 5.3 Factory-Recommended Branch Circuit Protection (400 V Class)
Drive Model
Semiconductor Protection Fuse
Model
Manufacturer: EATON/Bussmann
4002 FWH-50B
4004 FWH-50B
4005 FWH-50B
4007 FWH-60B
4009 FWH-60B
4012 FWH-60B
4018 FWH-80B
4023 FWH-90B
4031 FWH-150B
4038 FWH-200B
4044 FWH-200B
4060 FWH-225A
4075 FWH-250A
4089 FWH-275A
Drive Model
Semiconductor Protection Fuse
Model
Manufacturer: EATON/Bussmann
4103 FWH-275A
4140 FWH-300A
4168
FWH-325A
FWH-400A
*1
4208 FWH-500A
4250 FWH-600A
4296 FWH-700A
4371 FWH-800A
4389 FWH-1000B
4453 FWH-1200B
4568 FWH-1200B
4675
FWH-1400A
FWH-1600A
*1
*1 Yaskawa recommends a fuse with a large rated current for applications with repeated loads.
■ CE Standards Compliance for DC Power Supply Input
To comply with CE Standards, install a fuse for the DC power supply input.
Figure 5.3 shows a wiring example for a DC power supply that has two drives connected in parallel.
