Parameter List
11
11.10 H: Terminal Functions
YASKAWA SIEPC71061705H GA700 Series Technical Manual 539
Setting Value Function Description Ref.
122 !Mechanical Weakening
Detection
The terminal deactivates when the drive detects mechanical weakening.
844
12F !Maintenance
Notification
The terminal deactivates when drive components are at their estimated maintenance period.
Tells you about the maintenance period for these items:
• IGBT
• Cooling Fan
• Capacitor
• Soft charge bypass relay
844
130 !During Torque Limit
The terminal deactivates when the torque reference is the torque limit set with L7 parameters, H3-02, H3-06, or
H3-10 [MFAI Function Selection].
844
131 !During Speed Limit
The terminal deactivates when the speed limit is active.
844
132 !In Speed Limit During
Trq Ctrl
The motor accelerates in the forward direction or the reverse direction after enabling torque control and the
externally-input torque reference is disproportionate to the load. The output terminal deactivates when this speed is
not higher than a constant speed and the motor speed is at the speed limit. This does not include operation when the
drive is stopped.
844
133 !Zero Servo Complete
The terminal deactivates when positioning in the range set with b9-02 [Zero Servo Completion Window] completes
after sending the Zero-Servo command.
844
137 !During Frequency
Output
The terminal deactivates when the drive outputs frequency.
ON : The drive is not outputting frequency.
OFF : The drive is outputting frequency.
844
138 !Drive Enabled
This terminal deactivates when the H1-xx = 16A [Drive Enable] terminal deactivates.
844
139 !Watt Hour Pulse Output
Outputs the pulse that shows the watt hours.
844
13C !LOCAL Control
Selected
The terminal deactivates when the Run command source or frequency reference source is LOCAL.
ON : REMOTE
OFF : LOCAL
844
13D !During Speed Search
The terminal deactivates when the drive does speed search.
844
13E !PID Feedback Low
The terminal deactivates when the drive detects FbL [PID Feedback Loss].
844
13F !PID Feedback High
The terminal deactivates when the drive detects FbH [Excessive PID Feedback].
844
14A !During KEB Ride-Thru
The terminal deactivates when the drive executes the KEB Ride-Thru function.
844
14B !During Short Circuit
Braking
The terminal deactivates during Short Circuit Braking.
Note:
When A1-02 = 8 [Control Method Selection = EZ Vector Control], this function is available when you use a
PM motor.
844
14C !During Fast Stop
The terminal deactivates when the fast stop is in operation.
844
14D !oH Pre-Alarm
Reduction Limit
The terminal deactivates when L8-03 = 4 [Overheat Pre-Alarm Selection = Operate at Reduced Speed (L8-19)]
and oH [Heatsink Overheat] does not clear after the drive decreases the frequency for 10 cycles.
844
14E !Braking Transistor Fault
(rr)
The terminal deactivates when the internal braking transistor overheats and the drive detects an rr [Dynamic
Braking Transistor Fault] fault.
844
14F !Braking Resistor
Overheat (rH)
The terminal deactivates when the braking resistor overheats and the drive detects an rH [Braking Resistor
Overheat] fault.
844
160 !Internal Cooling Fan
Failure
The terminal deactivates when the drive detects a cooling fan failure in the drive.
844
161 !RotorPositionDetection
Complete
The terminal deactivates when drive receives a Run command and the drive detects the motor magnetic pole
position of the PM motor.
844
