YASKAWA GA700 Series

Parameter List
11
11.21 Defaults by Drive Model and Duty Rating ND/HD
YASKAWA SIEPC71061705H GA700 Series Technical Manual 603
No.
*1
Name Unit Default
- Drive Model - 2004 2006 2010
C6-01
Normal / Heavy
Duty Selection
-
HD ND HD ND HD ND
0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 62 63 65
E2-11
(E4-11)
Motor Rated
Power
kW 0.4 0.75 0.75 1.1 1.5 2.2
L8-38
Carrier Frequency
Reduction
- 2 2 2 2 2 2
n1-01
Hunting
Prevention
Selection
- 1 1 1 1 1 1
n1-03
Hunting
Prevention Time
Constant
ms 10 10 10 10 10 10
n1-16
Hunting
Prevention High
Fc Gain
- 0.50 0.50 0.50 0.50 0.50 0.50
n5-02
Motor Inertia
Acceleration
Time
s 0.178 0.142 0.142 0.142 0.166 0.145
*1 Parameters within parentheses are for motor 2.
No.
*1
Name Unit Default
- Drive Model - 2012 2018 2021 2030
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 66 67 68 6A
E2-11
(E4-11)
Motor Rated
Power
kW 2.2 3.0 3.0 3.7 3.7 5.5 5.5 7.5
b3-04
V/f Gain
during Speed
Search
% 100 100 100 100 100 100 100 100
b3-06
Speed
Estimation
Current Level
1
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-08
Speed
Estimation
ACR P Gain
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
b3-26
Direction
Determination
Level
- 1000 1000 1000 1000 1000 1000 1000 1000
b8-03
Energy Saving
Filter Time
s 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
b8-04
Energy Saving
Coefficient
Value
- 156.8 136.4 136.4 122.9 122.9 94.75 94.75 72.69
C5-17
(C5-37)
Motor Inertia kgm
2
0.0088 0.0158 0.0158 0.0158 0.0158 0.0255 0.026 0.037
C6-02
Carrier
Frequency
Selection
- 1 7 1 7 1 7 1 7
E2-01
(E4-01)
Motor Rated
Current (FLA)
A 8.5 11.4 11.4 14 14 19.6 19.6 26.6
E2-02
(E4-02)
Motor Rated
Slip
Hz 2.9 2.7 2.7 2.73 2.73 1.5 1.5 1.3
E2-03
(E4-03)
Motor No-
Load Current
A 3 3.7 3.7 4.5 4.5 5.1 5.1 8
E2-05
(E4-05)
Motor Line-
to-Line
Resistance
Ω 1.601 1.034 1.034 0.771 0.771 0.399 0.399 0.288
