YASKAWA GA700 Series

11.21 Defaults by Drive Model and Duty Rating ND/HD
604 YASKAWA SIEPC71061705H GA700 Series Technical Manual
No.
*1
Name Unit Default
- Drive Model - 2012 2018 2021 2030
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 66 67 68 6A
E2-11
(E4-11)
Motor Rated
Power
kW 2.2 3.0 3.0 3.7 3.7 5.5 5.5 7.5
E2-06
(E4-06)
Motor
Leakage
Inductance
% 18.4 19 19 19.6 19.6 18.2 18.2 15.5
E2-10
(E4-10)
Motor Iron
Loss
W 77 91 91 112 112 172 172 262
E5-01
PM Motor
Code
Selection
- 1206 1206 FFFF FFFF 1208 1208 120A 120A
L2-02
Power Loss
Ride Through
Time
s 0.5 0.5 1 1 1 1 1 1
L2-03
Minimum
Baseblock
Time
s 0.5 0.5 0.5 0.6 0.6 0.7 0.7 0.8
L2-04
Powerloss V/f
Recovery
Ramp Time
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L2-05
Undervoltage
Detection Lvl
(Uv1)
- 190 190 190 190 190 190 190 190
L3-24
Motor Accel
Time @ Rated
Torque
s 0.145 0.145 0.145 0.154 0.154 0.168 0.168 0.175
L8-02
Overheat
Alarm Level
°C 124 124 110 110 110 110 110 110
L8-09
Output
Ground Fault
Detection
- 1 1 1 1 1 1 1 1
L8-38
Carrier
Frequency
Reduction
- 2 2 2 2 2 2 2 2
n1-01
Hunting
Prevention
Selection
- 1 1 1 1 1 1 1 1
n1-03
Hunting
Prevention
Time Constant
ms 10 10 10 10 10 10 10 10
n1-16
Hunting
Prevention
High Fc Gain
- 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
n5-02
Motor Inertia
Acceleration
Time
s 0.145 0.145 0.145 0.154 0.154 0.168 0.168 0.175
*1 Parameters within parentheses are for motor 2.
No.
*1
Name Unit Default
- Drive Model - 2042 2056 2070 2082
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 6B 6D 6E 6F
E2-11
(E4-11)
Motor Rated
Power
kW 7.5 11 11 15 15 18.5 18.5 22
b3-04
V/f Gain
during Speed
Search
% 100 100 100 100 100 100 100 100
b3-06
Speed
Estimation
Current Level
1
- 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
