YASKAWA GA700 Series

Parameter List
11
11.21 Defaults by Drive Model and Duty Rating ND/HD
YASKAWA SIEPC71061705H GA700 Series Technical Manual 611
No.
*1
Name Unit Default
- Drive Model - 4009 4012 4018 4023
C6-01
Normal /
Heavy Duty
Selection
-
HD ND HD ND HD ND HD ND
0 1 0 1 0 1 0 1
o2-04
Drive Model
(KVA)
Selection
Hex. 96 97 99 9A
E2-11
(E4-11)
Motor Rated
Power
kW 3.0 4.0 4.0 5.5 5.5 7.5 7.5 11
E2-05
(E4-05)
Motor Line-
to-Line
Resistance
Ω 4.360 3.333 3.333 1.595 1.595 1.152 1.152 0.922
E2-06
(E4-06)
Motor
Leakage
Inductance
% 19 19.3 19.3 18.2 18.2 15.5 15.5 19.6
E2-10
(E4-10)
Motor Iron
Loss
W 105 130 130 193 193 263 263 385
E5-01
PM Motor
Code
Selection
- FFFF FFFF 1238 1238 123A 123A 123B 123B
L2-02
Power Loss
Ride Through
Time
s 0.5 0.5 0.5 0.5 0.8 0.8 1 1
L2-03
Minimum
Baseblock
Time
s 0.5 0.6 0.6 0.7 0.7 0.8 0.8 0.9
L2-04
Powerloss V/f
Recovery
Ramp Time
s 0.3 0.3 0.3 0.3 0.3 0.3 0.3 0.3
L2-05
Undervoltage
Detection Lvl
(Uv1)
- 380 380 380 380 380 380 380 380
L3-24
Motor Accel
Time @ Rated
Torque
s 0.145 0.154 0.154 0.168 0.168 0.175 0.175 0.265
L8-02
Overheat
Alarm Level
°C 100 100 100 100 105 105 105 105
L8-09
Output
Ground Fault
Detection
- 1 1 1 1 1 1 1 1
L8-38
Carrier
Frequency
Reduction
- 2 2 2 2 2 2 2 2
n1-01
Hunting
Prevention
Selection
- 1 1 1 1 1 1 1 1
n1-03
Hunting
Prevention
Time Constant
ms 10 10 10 10 10 10 10 10
n1-16
Hunting
Prevention
High Fc Gain
- 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
n5-02
Motor Inertia
Acceleration
Time
s 0.145 0.154 0.154 0.168 0.168 0.175 0.175 0.265
*1 Parameters within parentheses are for motor 2.
