12.2 A: Initialization Parameters
630 YASKAWA SIEPC71061705H GA700 Series Technical Manual
Table 12.14 Best Parameter Settings for Hoist Applications
No. Name Optimal Value
A1-02 Control Method Selection 2: Open Loop Vector
b1-01 Frequency Reference Selection 1 0: Keypad
b6-01 Dwell Reference at Start 3.0 Hz
b6-02 Dwell Time at Start 0.3 s
C1-01 Acceleration Time 1 3.0 s
C1-02 Deceleration Time 1 3.0 s
C6-01 Normal / Heavy Duty Selection 0: Heavy Duty Rating
C6-02 Carrier Frequency Selection 2: 5 kHz
d1-01 Reference 1 6.00 Hz
d1-02 Reference 2 30.00 Hz
d1-03 Reference 3 50.00 Hz
E1-03 V/f Pattern Selection F: Custom
H2-01 Terminal M1-M2 Function Selection 5: Frequency Detection 2
H2-02 Terminal M3-M4 Function Selection 37: During Frequency Output
H3-06 Terminal A3 Function Selection F: Not Used
L2-03 Minimum Baseblock Time 0.3 s
L3-04 Stall Prevention during Decel 0: Disabled
L4-01 Speed Agree Detection Level 2.0 Hz
L4-02 Speed Agree Detection Width 0.0 Hz
L6-01 Torque Detection Selection 1 8: UL @ RUN - Fault
L6-02 Torque Detection Level 1 2%
L6-03 Torque Detection Time 1 0.5 s
L8-05 Input Phase Loss Protection Sel 1: Enabled
L8-07 Output Phase Loss Protection Sel 1: Fault when one phase is lost
L8-38 Carrier Frequency Reduction 1: Enabled below 6 Hz
L8-41 High Current Alarm Selection 1: Enabled
The drive saves the parameters in Table 12.15 as user parameters.
Table 12.15 Parameters Saved as User Parameters with the Hoist Preset
User Parameter No. Parameter No. Saved Name
A2-01 A1-02 Control Method Selection
A2-02 b1-01 Frequency Reference Selection 1
A2-03 b6-01 Dwell Reference at Start
A2-04 b6-02 Dwell Time at Start
A2-05 C1-01 Acceleration Time 1
A2-06 C1-02 Deceleration Time 1
A2-07 C6-02 Carrier Frequency Selection
A2-08 d1-01 Reference 1
A2-09 d1-02 Reference 2
A2-10 d1-03 Reference 3
A2-11 E1-08 Mid Point AVoltage
A2-12 H2-01 Terminal M1-M2 Function Selection
A2-13 L1-01 Motor Overload (oL1) Protection
A2-14 L4-01 Speed Agree Detection Level
A2-15 L6-02 Torque Detection Level 1
A2-16 L6-03 Torque Detection Time 1
