12.2 A: Initialization Parameters
YASKAWA SIEPC71061705H GA700 Series Technical Manual 631
7 : Crane (Traveling)
The drive automatically sets the parameters in Table 12.16 for a traveling application.
Table 12.16 Optimal Settings for Traveling Applications
No. Name Optimal Value
A1-02 Control method selection 0: V/f Control
b1-01 Frequency Reference Selection 1 0: Keypad
C1-01 Acceleration Time 1 3.0 s
C1-02 Deceleration Time 1 3.0 s
C6-01 Normal / Heavy Duty Selection 0: Heavy Duty Rating
C6-02 Carrier Frequency Selection 2: 5 kHz
d1-01 Reference 1 6.00 Hz
d1-02 Reference 2 30.00 Hz
d1-03 Reference 3 50.00 Hz
H1-05 Terminal S5 Function Selection 3: Multi-Step Speed Reference 1
H1-06 Terminal S6 Function Selection 4: Multi-Step Speed Reference 2
H2-01 Terminal M1-M2 Function Selection 37: During Frequency Output
H2-02 Terminal M3-M4 Function Selection 37: During Frequency Output
H3-06 Terminal A3 Function Selection 1F: Not Used
L3-04 Stall Prevention during Decel 0: Disabled
L8-05 Input Phase Loss Protection Sel 1: Enabled
L8-07 Output Phase Loss Protection Sel 1: Fault when one phase is lost
L8-38 Carrier Frequency Reduction 1: Enabled below 6 Hz
L8-41 High Current Alarm Selection 1: Enabled
The drive saves the parameters in Table 12.17 as user parameters.
Table 12.17 Parameters Saved as User Parameters with the Traveling Preset
User Parameter No. Parameter No. Saved Name
A2-01 b1-01 Frequency Reference Selection 1
A2-02 C1-01 Acceleration Time 1
A2-03 C1-02 Deceleration Time 1
A2-04 C6-02 Carrier Frequency Selection
A2-05 d1-01 Reference 1
A2-06 d1-02 Reference 2
A2-07 d1-03 Reference 3
A2-08 E2-01 Motor Rated Current (FLA)
A2-09 H1-05 Terminal S5 Function Selection
A2-10 H1-06 Terminal S6 Function Selection
A2-11 H2-01 Terminal M1-M2 Function Selection
A2-12 L1-01 Motor Overload (oL1) Protection
■ Notes for Elevator Applications
When you use the drive for elevator applications, read the safety descriptions and precautions, and safely and
correctly use the device.
Conditions to Open and Close the Brake
Set L4-07 = 0 [Speed Agree Detection Selection = No Detection during Baseblock] to open and close the holding
brake.
When L4-07 = 1 [Detection Always Enabled], the output frequency increases when you input the Run command
although the external baseblock command is input. Because of this, speed detection operates and will open the
brake signal.
