12 Parameter Details
12.11 o: Keypad-Related Settings
◆ o5: Log Function
The data log function saves drive status information as a CSV file in the micro SD memory
card in the keypad. Monitors Ux-xx are the source of data log information.
There are two types of data log functions:
 Long-term data log: Saves data continuously over a long time period.
 Short-term data log: Saves data for a certain time period before and after the detection of
a trigger with a short sampling cycle.
You can record a maximum of 10 monitors for long-term data logs and a maximum of four
monitors for short-term data logs.
Change the LCD keypad screen from the main menu to the Diagnostic Tools screen and
select the data log function. Set the number of the monitor to record, the sampling time,
and the trigger, then start to record the data log.
Table 12.79 Setting Parameters for Data Log Items
No.
Name
De fault
Data Log Monitors
o5-03
Log Monitor Data 1
101
U1-01 [Frequency Reference]
o5-04
Log Monitor Data 2
102
U1-02 [Output Frequency]
o5-05
Log Monitor Data 3
103
U1-03 [Output Current]
o5-06
Log Monitor Data 4
107
U1-07 [DC Bus Voltage]
o5-07
Log Monitor Data 5
108
U1-08 [Output Power]
o5-08
Log Monitor Data 6
000
Not selected
o5-09
Log Monitor Data 7
000
Not selected
o5-10
Log Monitor Data 8
000
Not selected
o5-11
Log Monitor Data 9
000
Not selected
o5-12
Log Monitor Data 10
000
Not selected
Note:  Do not de-energize the drive or disconnect the keypad from the drive during log
transfer communication. Failure to obey can cause the log function to fail after you
restore power or connect the keypad.
 You can use a Micro SDHC card a maximum of 32 GB capacity.
 For a short-term data log, o5-03 [Log Monitor Data 1] to o5-06 [Log Monitor Data
4] are enabled.
◼ Log File Specifications
It e m
Sp e cification
File storage location
A folder called [Log_File] is created in the root directory of the micro SD card.
Filename
Long-term data log: GLOG0xxx.csv
Note: [xxx] identifies a 3-digit decimal number
Short-term data log: SLOG0xxx.csv
Note: [xxx] identifies a 3-digit decimal number
Maximum number of
files
Long-term data log: 999 (GLOG0001.csv to GLOG0999.csv)
Short-term data log: 999 (SLOG0001.csv to SLOG0999.csv)
Character code
ASCII code
Line break code
<CR><LF>
Separating character
[ , ] (Commas)
Header Rows
First Row: Drive information including Drive Model, software version, control method,
sampling time, and trigger settings
Second Row: Log data information including the monitor number, number decimal points,
and unit code
◼ Log File Configuration
The [Log_Files] folder is created in the root directory of the micro SD card. This is where the
log data is stored as CSV files. Log data files are created in this configuration. The number
of rows changes when the number of selected monitors change.
First Row
Drive information
Second Row
Log data information
Third Row
Log data 1
:
Log data 2
:
Log data 3
:
:
Last Row
Log data n
