Chapter 1: Cyclone IV Device Datasheet 1–29
Switching Characteristics
December 2016 Altera Corporation Cyclone IV Device Handbook,
Volume 3
t
LOCK
(3)
— ——1——1—— 1——1——1ms
Notes to Table 1–31:
(1) Applicable for true RSDS and emulated RSDS_E_3R transmitter.
(2) Cyclone IV E devices—true RSDS transmitter is only supported at the output pin of Row I/O Banks 1, 2, 5, and 6. Emulated RSDS transmitter is supported at the
output pin of all I/O Banks.
Cyclone IV GX devices—true RSDS transmitter is only supported at the output pin of Row I/O Banks 5 and 6. Emulated RSDS transmitter is supported at the output
pin of I/O Banks 3, 4, 5, 6, 7, 8, and 9.
(3) t
LOCK
is the time required for the PLL to lock from the end-of-device configuration.
(4) Cyclone IV E 1.0 V core voltage devices only support C8L, C9L, and I8L speed grades. Cyclone IV E 1.2 V core voltage devices only support C6, C7, C8, I7, and A7
speed grades. Cyclone IV GX devices only support C6, C7, C8, and I7 speed grades.
Table 1–31. RSDS Transmitter Timing Specifications for Cyclone IV Devices
(1), (2), (4)
(Part 2 of 2)
Symbol Modes
C6 C7, I7 C8, A7 C8L, I8L C9L
Unit
Min Typ Max Min Typ Max Min Typ Max Min Typ Max Min Typ Max
Table 1–32. Emulated RSDS_E_1R Transmitter Timing Specifications for Cyclone IV Devices
(1), (3)
(Part 1 of 2)
Symbol Modes
C6 C7, I7 C8, A7 C8L, I8L C9L
Unit
Min Typ Max Min Typ Max Min Typ Max Min Typ Max Min Typ Max
f
HSCLK
(input
clock
frequency)
×10 5 — 85 5 — 85 5 — 85 5 — 85 5 — 72.5 MHz
×8 5 — 85 5 — 85 5 — 85 5 — 85 5 — 72.5 MHz
×7 5 — 85 5 — 85 5 — 85 5 — 85 5 — 72.5 MHz
×4 5 — 85 5 — 85 5 — 85 5 — 85 5 — 72.5 MHz
×2 5 — 85 5 — 85 5 — 85 5 — 85 5 — 72.5 MHz
×1 5 — 170 5 — 170 5 — 170 5 — 170 5 — 145 MHz
Device
operation in
Mbps
×10 100 — 170 100 — 170 100 — 170 100 — 170 100 — 145 Mbps
×8 80 — 170 80 — 170 80 — 170 80 — 170 80 — 145 Mbps
×7 70 — 170 70 — 170 70 — 170 70 — 170 70 — 145 Mbps
×4 40 — 170 40 — 170 40 — 170 40 — 170 40 — 145 Mbps
×2 20 — 170 20 — 170 20 — 170 20 — 170 20 — 145 Mbps
×1 10 — 170 10 — 170 10 — 170 10 — 170 10 — 145 Mbps
t
DUTY
— 45 — 55 45 — 55 45 — 55 45 — 55 45 — 55 %
TCCS — — — 200 — — 200 — — 200 — — 200 — — 200 ps
Output jitter
(peak to peak)
— — — 500 — — 500 — — 550 — — 600 — — 700 ps
t
RISE
20 – 80%,
C
LOAD
=
5pF
— 500 — — 500 — — 500 — — 500 — — 500 — ps
t
FALL
20 – 80%,
C
LOAD
=
5pF
— 500 — — 500 — — 500 — — 500 — — 500 — ps
