Chapter 1: Cyclone IV Device Datasheet 1–31
Switching Characteristics
December 2016 Altera Corporation Cyclone IV Device Handbook,
Volume 3
Table 1–34. True LVDS Transmitter Timing Specifications for Cyclone IV Devices
(1), (3)
Symbol Modes
C6 C7, I7 C8, A7 C8L, I8L C9L
Unit
Min Max Min Max Min Max Min Max Min Max
f
HSCLK
(input
clock
frequency)
×10 5 420 5 370 5 320 5 320 5 250 MHz
×8 5 420 5 370 5 320 5 320 5 250 MHz
×7 5 420 5 370 5 320 5 320 5 250 MHz
×4 5 420 5 370 5 320 5 320 5 250 MHz
×2 5 420 5 370 5 320 5 320 5 250 MHz
×1 5 420 5 402.5 5 402.5 5 362 5 265 MHz
HSIODR
×10 100 840 100 740 100 640 100 640 100 500 Mbps
×8 80 840 80 740 80 640 80 640 80 500 Mbps
×7 70 840 70 740 70 640 70 640 70 500 Mbps
×4 40 840 40 740 40 640 40 640 40 500 Mbps
×2 20 840 20 740 20 640 20 640 20 500 Mbps
×1 10 420 10 402.5 10 402.5 10 362 10 265 Mbps
t
DUTY
—45554555455545554555%
TCCS — — 200 — 200 — 200 — 200 — 200 ps
Output jitter
(peak to peak)
— — 500 — 500 — 550 — 600 — 700 ps
t
LOCK
(2)
——1—1—1—1—1ms
Notes to Table 1–34:
(1) Cyclone IV E—true LVDS transmitter is only supported at the output pin of Row I/O Banks 1, 2, 5, and 6.
Cyclone IV GX—true LVDS transmitter is only supported at the output pin of Row I/O Banks 5 and 6.
(2) t
LOCK
is the time required for the PLL to lock from the end-of-device configuration.
(3) Cyclone IV E 1.0 V core voltage devices only support C8L, C9L, and I8L speed grades. Cyclone IV E 1.2 V core voltage devices only support
C6, C7, C8, I7, and A7 speed grades. Cyclone IV GX devices only support C6, C7, C8, and I7 speed grades.
Table 1–35. Emulated LVDS Transmitter Timing Specifications for Cyclone IV Devices
(1), (3)
(Part 1 of 2)
Symbol Modes
C6 C7, I7 C8, A7 C8L, I8L C9L
Unit
Min Max Min Max Min Max Min Max Min Max
f
HSCLK
(input
clock
frequency)
×10 5 320 5 320 5 275 5 275 5 250 MHz
×8 5 320 5 320 5 275 5 275 5 250 MHz
×7 5 320 5 320 5 275 5 275 5 250 MHz
×4 5 320 5 320 5 275 5 275 5 250 MHz
×2 5 320 5 320 5 275 5 275 5 250 MHz
×1 5 402.5 5 402.5 5 402.5 5 362 5 265 MHz
HSIODR
×10 100 640 100 640 100 550 100 550 100 500 Mbps
×8 80 640 80 640 80 550 80 550 80 500 Mbps
×7 70 640 70 640 70 550 70 550 70 500 Mbps
×4 40 640 40 640 40 550 40 550 40 500 Mbps
×2 20 640 20 640 20 550 20 550 20 500 Mbps
×1 10 402.5 10 402.5 10 402.5 10 362 10 265 Mbps
