Cable and Antenna Measurements 3-7 Measurement Setup
Pass/Fail Messages
Figure 3-22 shows the Pass/Fail message. Note that in the Fail message,
Upper (U) or Lower (L) or both (U,L) are displayed. To change the size and
location of the Pass/Fail message, (when the Limit menu is displayed) tap the
small circled arrow in the lower-right corner of the large format message box.
The circled arrow is in the upper-left corner when the message is in small
format.
Figure 3-22. Pass/Fail Message Turned On
To Next Page
