S820E UG PN: 10580-00343 Rev. H 5-3
Classic Mode Operation 5-2 Classic Mode and Advanced Mode
In Advanced Mode, two additional submenu keys are available to control the
measurement display. In the “Measurement Menu” on page 3-55, the
Display Format key toggles Single and Dual trace displays (refer to “Dual
Display Format” on page 2-25). The Active Display key toggles the Top or
Bottom trace to be active.
Table 5-1. Menu Differences Between Classic Mode and Advanced Mode
Classic Mode Advanced Cable and Antenna Mode
Meas Mode Menu
“Measurement Menu” on page 3-55
Freq – SWR “VSWR” on page 3-55
Freq – Return Loss “Return Loss” on page 3-55
Freq – Cable Loss
(one port)
“Cable Loss” on page 3-55
Freq – Cable Loss
(two port, ext. sensor)
“Transmission (2-Port)” on page 3-56
“Transmission (Ext. Sensor)” on page 3-56
DTF – SWR “DTF VSWR” on page 3-55
DTF – Return Loss “DTF Return Loss” on page 3-55
— “Smith Chart” on page 3-56
— “1-Port Phase” on page 3-57
Freq/Dist Menu
“Freq/Dist Menu” on page 3-58
F1 “Start Frequency (F1)” on page 3-58
F2 “Stop Frequency (F2)” on page 3-58
D1 “Start Distance (D1)” on page 3-58
D2 “Stop Distance (D2)” on page 3-58
More “DTF Setup” on page 3-59
Marker Menu
Refer to Figure 5-2 on page 5-4 for “Classic”
mode marker menu structure. Refer to “Marker
Menu” on page 5-6 for menu descriptions.
Meas/Disp Menu
Refer to “Sweep Menu” on page 3-67 and “Trace
Menu” on page 3-69
Note
Also refer to Chapter 3 for descriptions of other menus not
specifically mentioned in Table 5-1.
