S820E UG PN: 10580-00343 Rev. H 7-11
Calibration, VNA 7-3 Calibration Setup
Table 7-1. Coax Dut Connectors and Cal Kits
Coaxial Connector Name Available Cal Kits
N-Type (male)
OSLN50, OSLN50-1, OSLN50A-8,
OSLN50A-18, TOSLN50A-8,
TOSLN50A-18
N-Type (female)
OSLNF50, OSLNF50-1,
OSLNF50A-8, OSLNF50A-18,
TOSLNF50A-8, TOSLNF50A-18
K (male)
OSLK50, TOSLK50A-20,
TOSLK50A-40
K (female)
OSLKF50, TOSLKF50A-20,
TOSLKF50A-40
7/16 (male) 2000-1618-R, 2000-767
7/16 (female) 2000-1619-R, 2000-768
SMA (male) 3650 (male components of kit)
SMA (female) 3650 (female components of kit)
TNC (male) 1091-53, Open
TNC (male) 1091-54, Short
TNC (male) 1015-55, Termination
TNC (female) 1091-55, Open
TNC (female) 1091-56, Short
TNC (female) 1015-54, Termination
User 1: Coax User 1 (Coax)
User 2: Coax User 2 (Coax)
User 3: Coax User 3 (Coax)
User 4: Coax User 2 (Coax)
