7-12 PN: 10580-00343 Rev. H S820E UG
7-3 Calibration Setup Calibration, VNA
If you are using custom connectors that are not already listed, then the
Site Master S820E allows you to create up to four User DUT connectors and
corresponding User Cal Kits. Choose one of the User connectors from the
Port 1 DUT Connector list, as shown in Figure 7-8 on page 7-14. You can edit
the name of the DUT connector, as indicated on the Site Master screen.
For each User DUT connector, a corresponding User Cal Kit is selected, as
shown in Figure 7-9 on page 7-15. The coefficients for the calibration kit can
be edited, as indicated on the Site Master screen. Customizing the connectors
and calibration kit coefficients allows you to have the most flexibility in using
any calibration kit that may be required for your measurements.
Table 7-2. Waveguide DUT Connectors
Waveguide Connector Name
WG11A/R40 (3.30 to 4.90 GHz)
WG12/WR187/R48 (3.95 to 5.85 GHz)
WG13 (4.90 to 7.00 GHz)
WG14/WR137/R70 (5.85 to 8.20 GHz)
WG15/WR112/R84 (7.05 to 10.0 GHz)
WG16/WR90/R100 (8.20 to 12.4 GHz)
WG17/R120 (10.0 to 15.0 GHz)
WG18/WR62/R140 (12.4 to 18.0 GHz)
WG20/WR42/R220 (18.0 to 26.5 GHz)
WG22/WR28/R320 (26.5 to 40.0 GHz)
User 1: WG
User 2: WG
User 3: WG
User 4: WG
