Applied Biosystems 3500 User Manual

The elds in the Edit Assay dialog box (Figure 11
) are described in “Assay
seings“ on page 146.
Figure 11 Cr
eate new assay
Assay settings
Setting
Description
Assay Name Name of the assay.
Locked Prevents the item from being edited.
Color Color code for the assay when it is displayed in the As
sign Plate Contents screen (if
Assay Color is selected for Show In Wells).
Application Type Sequencing or F
ragment.
Chapter 7 Manage library resources
Assays library
7
146
3500/3500xL Genetic Analyzer User Guide—Data Collection Software v3.1

Applied Biosystems 3500 Specifications

General

Number of capillaries	8
Capillary Length	50 cm
Laser	Solid-state laser
Instrument Type	Capillary electrophoresis system
Technology	Capillary Electrophoresis (CE)
Weight	95 kg
Power Requirements	100–240 V
