Applied Biosystems 3500 User Manual

Instrument specifications
Instrument specifications
Table 10 Applied Biosystems
™
3500/3500xL Genetic Analyzer physical dimensions,
weight, and power consumption
Parameter Instrument footprint
Recommended
clearance
Depth 61 cm (24 in.) 25.4 cm (10 in.)
[1]
Width 61 cm (24 in.) (closed door)
122 cm (48 in.) (open door)
158 cm (62 in.)
[2]
Height 72 cm (28.3 in.) 31 cm (12 in.)
Weight »82 kg (180 lbs)
[1]
A
t the rear of the instrument to ensure adequate airflow and cooling
[2]
For the instrument, computer, and computer monitor.
Table 11 Computer dimensions and weight
Parameter Computer Monitor Keyboard
Depth 41.7 cm (16.42 in.) 19.3 cm (7.6 in.) 44.7 cm (17.5 in.)
Width 17.5 cm (6.89 in.) 44.7 cm (17.5 in.) 15.25 cm (6 in.)
Height 37.4 cm (14.7 in.) 36.6 cm (14.4 in.) 5 cm (2 in.)
Weight 9.6. kg (21 lbs) 6.9 kg (15.2 lbs) 0.09 kg (0.2 lbs)
Table 12 Applied Biosystems
™
3500/3500xL Genetic Analyzer operating specifications
Component Specification
Laser
• Long-life, single-line 505 nm, solid-state laser
excitation source
• Laser Output power 20mW
• Beam divergence 1.4 mrad
LED
• Emitting color Natural White
• Luminous Intensity 250 Cd
Electrophoresis Voltage Up to 20 kV
Oven Temperature Active temperature control from 18°C to 70°C
C
286
3500/3500xL Genetic Analyzer User Guide—Data Collection Software v3.1

Applied Biosystems 3500 Specifications

General

Number of capillaries	8
Capillary Length	50 cm
Laser	Solid-state laser
Instrument Type	Capillary electrophoresis system
Technology	Capillary Electrophoresis (CE)
Weight	95 kg
Power Requirements	100–240 V
