Figure 26 Create New Sizecalling Protocol—QC Settings
Sizecalling protocol—Analysis settings
Setting
Description
Protocol Name Name of the protocol. Names must be unique.
Description Optional text entry.
Size standard Size standard definition in the software that corresponds to the dye set used
in the chemistry.
To apply normalization, select a normalization size standard (see
“Normalization size standards provided“ on page 171).
Chapter 7 Manage library resources
Sizecalling protocols library (primary analysis—fragment)
7
3500/3500xL Genetic Analyzer User Guide—Data Collection Software v3.1
181

Applied Biosystems 3500 Specifications

General

Number of capillaries	8
Capillary Length	50 cm
Laser	Solid-state laser
Instrument Type	Capillary electrophoresis system
Technology	Capillary Electrophoresis (CE)
Weight	95 kg
Power Requirements	100–240 V
