Applied Biosystems 3500 User Manual

Run modules and dye sets
Run modules
Table 5 Sequencing analysis run modules
Run module
type
Run module name
Configuration 23 hours Throughput
[1]
Perfor-
mance
Cap.
length
(cm)
Polymer
type
Run
time
(min)
3500
(8‑cap.)
3500xL
(24-cap.)
Contig.
Read
Length
(CRL)
[2]
Short read
sequencing
ShortReadSeq50_POP7
ShortReadSeq50_POP7xl
50 POP-7
™
£30 ³368 ³1104 ³300
Short read
sequencing
BigDye
XTerminator
™
BDxShortReadSeq50_POP7
BDxShortReadSeq50_POP7xl
50 POP-7
™
£30 ³368 ³1104 ³300
Rapid
sequencing
RapidSeq50_POP6
RapidSeq50_POP6xl
50 POP-6
™
£65 ³168 ³504 ³450
RapidSeq50_POP7
RapidSeq50_POP7xl
50 POP-7
™
£40 ³280 ³840 ³500
Rapid
sequencing
RapidSeq36_POP4
RapidSeq36_POP4xl
36 POP-4
™
£45 ³240 ³720 ³400
RapidSeq36_POP6
RapidSeq36_POP6xl
36 POP-6
™
£65 ³168 ³504 ³600
RapidSeq36_POP7
RapidSeq36_POP7xl
36 POP-7
™
£30 ³368 ³1104 ³600
Rapid
sequencing
BigDye
XTerminator
™
BDxRapidSeq50_POP6
BDxRapidSeq50_POP6xl
50 POP-6
™
£65 ³168 ³504 ³450
BDxRapidSeq50_POP7
BDxRapidSeq50_POP7xl
50 POP-7
™
£40 ³280 ³840 ³500
Rapid
sequencing
BigDye
XTerminator
™
BDxRapidSeq36_POP4
BDxRapidSeq36_POP4xl
36 POP-4
™
£45 ³240 ³720 ³400
B
3500/3500xL Genetic Analyzer User Guide—Data Collection Software v3.1
281

Applied Biosystems 3500 Specifications

General

Number of capillaries	8
Capillary Length	50 cm
Laser	Solid-state laser
Instrument Type	Capillary electrophoresis system
Technology	Capillary Electrophoresis (CE)
Weight	95 kg
Power Requirements	100–240 V
