6. GUI orientation
6.36 Settings Menu > WebKit area
General
Main wor k area of the Setting Menu, where the user has access to a set of functions directly provided by the E2.
All of the functions described in t his sect ion can also be performed b y launching the web app directly from
the brow ser outside of the GUI. You ne ed to type the unit’s IP address into your browser’s address bar and
the E2 Web app will appear in the brow ser.
Description
There a re several tabs in this area:
Dashboard: The four submenus in the Dashboard window pr ovide access to card diagnostics software.
Tools: This menu allows us ers to D ownload software and perform Backup and Restore operations.
Help: This menu contains a list of frequently ask ed questions to he lp you implement your s ystem.
Contact us: Display information to Barco t ech s upport.
Follow u s: Display links to obtain mor e information about image p rocessing and Barco.
The following sections describe each tab of this area in detail:
"Settings Menu > WebKit area > Dashboard", page 145
"Settings Menu > WebKit area > Tools", page 1 49
"Settings Menu > WebKit area > Help", page 154
"Settings Menu > WebKit area > Contact us", page 155
"Settings Menu > WebKit area > Follow us", page 156
144
R5905948 E2 12/12/2014
