Barco E2 - Spare Parts Serviceable by All Users

10. Maintenance
10.3 Spare Parts Serviceable b y all users
Spare Parts list
P/N
Description
Comments
R767241K VFD Display assembly
R767246K VFD F ilter
R767260K Front Panel board
R767261K
System Power board
R767263K
Heatsink fan One for each Input, Output, Link and VPU card
R767264K
CPU m odule
R767265K
Motherboard Heatsink & Fan kit
R767267K
Power supply(PS) One PS only. System accepts two Power supplies
R767268K Front Rack ears
Includes hardware for both sides
R767269K
Cable Kit set Kit Contains:
• 1x VFD -to-System board cable
• 2x Fan tray-to-System board cables
• 1x Genlock-to-System flat cable
• 1x F ront Panel Keyboard-to-System flat cable
• 1x RJ45-to-System CAT5 Ethernet c able
• 1x USB- to-System 5-pin c able
R767270K
1RU fan tray The f ans are not available s eparately
R767271K
3RU fan tray The f ans are not available s eparately
R767272K
EMI filter
R767273K
Rear Rack ea rs (C onnector
protector)
Includes hardware for both sides
R767275K
Solid-State Memory
V327007
System Battery
R9004740 DVI Input Board
R9004741
SDI Output Board
R9004742
SDI Input Board
R9004743
HDMI Output B oard
R9004744
DP/HDMI Input Board
R9004745
DVI Output Board
Not available in release 1
R9004746
Link Card Board
R9004747 VPU Boa rd Internal board
R9004748
Genlock Board
R9004750
Link/CXP Cable
R5905948 E2 12/12/2014 217
