7. System Setup
7.18 Programming Menu > Select Thumbn ails for Inputs
General
In this procedure, you will a dd s elect thumbnails for the Input sources.
Prerequisite
Ensure that you are familiar with the Programming M enu. F or details on this menu, please refer to chapter "Programming
Menu", page 105.
(Optional) Update thumbnails from the E2
1. Click on t he Input tab on the top of the left hand side.
2. Click on the re fresh icon to rec eive the latest icon from the E2.
Image 7-3
(Optional) Update thumbnails from the PC memory
1. Click on t he Input tab on the top of the left hand side.
2. Click on the thumbnail icon .
Image 7-4
3. Double-Click in the black box next to input name.
4. Navigate the com puters le system to nd and select the d esired thumbnail to be us ed Select T humbnails from the PC memory.
R5905948 E2 12/12/2014
175
