6. GUI orientation

6.15 Conﬁguration Menu > Adjustment > Out put Conﬁguration

General

In the O utput menu users can a ssign output connectors to conﬁgurations and adjust signal parameters to m atch the display devices

connected to the unit

Output Card arrangement

Output cards occ upy slots 11 through 12 and right justiﬁed to slot 13. If we have an empty output slot, all output cards to the left of

that empty slot will be red. Red indicates that a lthough the card s will operate properly, outputs from these cards will not be available

at the m ultiviewer

Image 6-22

If the card with the connectors that are part o f an output c onﬁguration is missing, the card in the E2 graphic and the output conﬁgu-

ration in the conﬁguration list will be grayed out.

Also, if there is an existing output conﬁguration but the card in the slot is of different type, then again the conﬁguration will be grey ed

out.

Output Connector Grouping

The c onnectors can also be grouped together to deﬁ nea3Dof4Kconﬁguration. F or example, a projector that requires 2 DVI

connectors to pass 3D Left and Right eye signals. A lso 4 SDI connectors can be conﬁgured as a 4K output in order to c onnect to a

4K projector

There are several rules that apply when deﬁning an output conﬁguration:

1. O ne O utput conn ector can only be assigned to one output c onﬁgura tion.

2. O utputs in an output conﬁguration must be of the same type AND in the same slot or in adjacent slots. For example, cannot

have a HDMI connector and an SDI connector in the same output conﬁguration.

3. Max connectors for an ou tput conﬁguration = 4.

4. O nce output connectors are assigned to the sam e output conﬁguration, all se ttings for the output connectors will be synchro-

nized.

5. If an output connector is not assigned to a n ou tput conﬁgur ation,

- Output settings cannot be adjusted o n that conn ector.

- The connec tor cannot be assigned to a destination

Examples of 4K Valid Inputs:

Image 6-23

Examples of v alid 3D Inputs:

R5905948 E2 12/12/2014

Barco E2 User Manual
