10. Maintenance
10.30 3RU Fan Cable
Image 10-76
The 3RU ca ble assembly provides p ower to the 3RU fans from the S ystem-Po wer board.
One side of the cab le is attached to a m etal bracket that is accessib le after the 3RU fan tray is removed. Th e
other side of t he cable assembly connects to the System-Power board and is accessible w hen the bottom
pane l i s re moved
Concerned parts
R767269K
Cable K it S et
Necessary tools
• 1 x Phillips Screw driv e r #2
• Hex Sc re w driver
How to remove the 3RU Fan cable
1. Make sure the unit is placed in the upright position and the 3RU fan tray is removed
2. Locate the 3RU cable connector that is exposed after the 3RU fan tray is removed. The c onnector is attached on a metal bracket
that is vertically m ounted in the chassis.
Image 10-77
R5905948 E2 12/12/2014 265
