9. General operation example
9.1 Event requirements
Description
Inputs for the event are provided from a Windows PC, two AJA K iPROs file recorders, a n A pple Macbook and two video ca meras.
Several outputs are required as follows:
• Two program outputs for the projectors dedicated to the Main screen. Two PiPs are displayed that are equal in size and a re
side-by-side. Tw o looks are desired:
- One look displays the two video c lips simultaneously from the K iPRO s.
- The other look s hows the PowerPoint and the stage camera.
- Background will be pr ovided from a PC dual-head card.
• Single Screen S ite S creen: Displays the videos from two KiPRO S and two cameras. The images are a lways f ull screen and
transition on screen at 0.5 sec.
• A DSM monitor is required for camera adjustments.
• Two 2 monitors for multi-viewing.
Image 9-1
190 R5905948 E2 12/12/2014
