7. System Setup
7.3 Power up and Status check
General
Use the following s teps to power up y our E2 system and c heck system s tatus.
Prerequisite
Ensure that your system is p roperly ins talled and cabled.
Ensure that you are familiar with the System M enu. For details on all m enus, please refer to chapter "Front Panel Menu
orientation", page 45.
Power up system and check system status
1. Turn on the unit and wait while it initializes. During the initialization process the front panel displays: “Program Loading Please
Wait”.
The Status Men u is autom atically displayed after initialization is completed.
2. Power up all pe ripherals, such as display devices (projectors, monitors) and sources.
3. Turn on the PC and run the EM GUI s oftware.
The s yst e m conguration page is the rst pag e that appears when the EM GUI is launched.
4. On the St atu s Me nu:
- S ystem1 is the default value d isplayed as S ystem Name if this is the rst start of the unit. This name can be chan
ged in the
conguration page of th e GUI.
- Ensure E 2 is connected on the local network. If there is no internet c onnection, or if a DHCP server has not been found, the
IP a ddress is 000.000.000.000. In this c ase, re-check all Ethernet connections. A fter checking connections, if d e vices still
report “Not C onnected,” use the procedure "Communication setup", page 162.
160
R5905948 E2 12/12/2014
