7. System Setup
7.15 Configuration Menu > Add Aux D estinations
General
In this procedure, you will Add Aux Destinations from the defined outputs.
Prerequisite
• Ensure that you are familiar with the Configuration Menu. For details on this m enu, pleas e refer to chapter "Configuration
Menu", page 76
If more t han one A ux Destination is utilized, repeat the below steps until all Destinations are ad ded .
Add Aux Destinations
1. Click on the Destination tabtodefine destinations for the defined outputs.
2. From the diagram area click on the output that you want to be part of the destination.
3. Click on the +Add A ux Destination blue button to assign the output to the Aux destination .
4. When the de stination is created a box appears next to the E2 diagram.
(Optional) Edit the Name
1. Double click on “Destination1” in the Name list to edit the name.
2. When the area turns blue, click the eraser icon to clear the field.
3. Type a new name and hit enter when done.
(Optional) Adjust Destination Parameters
Click on the “Adjust” tab that is located on the top. From this menu you can adjust:
1. Edit the nam e.
2. Select Format v alue, color space and connector type.
3. Enable Tes t Patterns with ras ter box and enable diagonal m otion.
4. Define the Area of interest (AOI).
5. Perform color adjustments.
6. Read the timing parameters associated with the selected format.
7. Select SD I type and SMPT E standards.
(Optional) Delete Destinations
1. Click on the blue button Delete Destination(s).
2. From the Name list click on the “x” s pace next to the output(s) y ou wish to delete.
3. Hit the red button Delete Destination(s) button. All of the selected Destination(s) will be removed from the list.
172
R5905948 E2 12/12/2014
