6. GUI orientation
6.21 Programming Menu > Adjustment area
General
Situated on the right hand side of the screen is the Adjustment area. In this area users can configure Layers and Sources and
create User keys and Preset s.
Description
There a re several tabs in this area:
• Layers : Provides a list of the destinations. Under each destination a list of assigned lay ers and the background is provided.
• User Keys : Provides a list of user keys. User keys contains all (or a portion) of the current layer ’s attributes (such as border
color, size, effects, etc.). User K eys are no t applicable for A UX Destination.
• Templates * : List of templates. Templates contain a group of layers worth of information. Templates are not ap plicable for
AUX Destination.
• Presets : List of Pr esets. P resets contains a group of Destination worth of information.
• Adjustment : Based on what is selected in the Preview or P rogram canvas area, this is the panel where we are ad justing what
is s elected. F or exam ple if we select Layer1, we will be adjusting Layer1 settings.
• Source Adjustment: This panel is show n on the Adjust panel when a layer with a valid Source is selected.
(*) This feature will be implemented in a f uture release!
At the bottom of the area, there is a set of buttons allowing execute transition actions on selected Destinations.
The following sections desc ribe each panel of this are a in detail:
• "Programming M enu > Adjustment area > Layer configuration", page 120
• "Programming Men u > Adjus tment area > Back ground configuration", page 126
• "Programming Me nu > A djustment area > User keys c onfi guration", page 128
• "Programming M enu > A djustment area > P resets configuration", p age 130
• "Programming M enu > Adjustment area > Source adjustment", page 1 31
• "Programming Menu > Adjustment area > Global Transition Rate/Tra ns/Cut", page 133
R5905948 E2 12/12/2014
119
