Barco E2 - 10.1 E2 unit Overview

10. Maintenance
10.1 E2 unit Overview
Orientation and main components
Image 10-1
T To p 6 Mother B oard
F Front 7
Top Cover
1 Front Panel Knob 8 Front B rackets
2VFDDisplay 9EMIFilter
3
Front Cover Assembly
10 1RU Fan Tray
4 Rac k Ears 11 3RU Fan Tray
5VPUcards 12
Chassis
R5905948 E2 12/12/2014 215
