6. GUI orientation
6.16 Configuration Menu > Adjustment > D estination Configuration
General
Output configuration that are created in the previous menus ar e assigned to destination in the Destination Panel.
Description
Destination configuration menu is accessed by clicking on the Destination tab.
This menu provides:
• A list of all the destinations (Screen, Aux) already created on the system
(e.g. S creenDest1)
• A button to add screen des tination.
• A button to add Aux destination.
• A button to delete unused or o bsolete destination(s).
The user c an assign outputs to output configurations manually, automatically or delete ou tputs from configur ations.
Destination formats
Few w ords about destination formats:
• For S creen Destinations: All subsequent new output configurations added to the Screen Destination will have its output format
updated to match the Scr een Destination output format. If the first output config in the Screen Des tination is deleted and a new
output configuration is added, then the new output format becomes as the destination output format again.
• For AUX Destination: An AUX destination alway s assumes the format of the output configuration that is ass igned to it.
Rules
There several rules that apply when defi ning an Destination configuration:
1. Destinations accept only the same output connector types. SDI and HDMI connec tors cannot be mixed in the same destination.
2. Destinations accept only output configurations with the sam e n umber of output connec tors. For exam ple if the 1st output co n-
figuration add ed is an HDMI output c onfigur ation w ith 2 connectors, an HDMI output configuration with 1 connector c annot be
added to the same destination.
3. Cannot add an output c onfiguration to a destination if it i
s not c apable of u sing the O utput format s elected. F or example: A n
Output configuration has a total connector c apacity of 2 it cannot be assigned to a 4K destination.
4. Cannot add different output configurations with different number of output connectors. For exam ple if the 1st output configura-
tion added is a HDMI output configur ation with 2 connectors, an HDMI output configuration with 1 connector canno t be added
to the same destination.
More about AUX Destinations
Based on the layer mode, the user can create A UX Destination on an output card. Layer mode is set in the System Modifier Panel.
Layer Mode HDMI & SD I Output Card Max. Numb er of Ou tputs
2K (Single link) 4
Dual Link 2
4K - UHD 1
Color codes
Screens and Aux are represented graphically in the Diagram area.
Green: Output(s) have been assigned to the destination
Yellow: Output(s) have not been assigned to the destination.
R5905948 E2 12/12/2014 99
