10. Maintenance
10.31 1RU Fan Cable
Image 10-82
The 1RU ca ble assembly provides p ower to the 1RU fans from the S ystem-Po wer board.
One side of the cable is attached to a m etal bracket that is acce ssible after the 3RU and the 1RU fan trays are
removed. The other side of the cable assembly co nnects t o the System-Pow er bo ard an d is accessible wh en
the bottom panel is remo ved.
Concerned parts
R767269K
Cable K it S et
Necessary tools
• 1 x Phillips Screw driv e r #2
• Hex Sc re w driver
How to remove the 1RU Fan cable
1. Make sure the unit is placed in the upright position and the 3RU and 1RU fan trays ar e removed.
2. Locate the 1RU cable connector that is exposed after the 1RU fan tray is removed. The c onnector is attached on a metal bracket
that is horizontally mounted in the chassis.
268
R5905948 E2 12/12/2014
