A. Specifications
A.1 Specifications of E2
Overview
Genlock Genlock: Reference Input/Loop on BNC connectors; Analog Bi-level an d Blackburst at
SD and Tri-level at H D
Communication Ethernet RJ-45, 1000/100/10 M bps au tosense
Dimensions
• Height: 17.8 cm (7.0 in) - 4 RU Rackmount
• Width: 43.2 cm (17.0 in)- without chassis handles, 48.3 c m (19 in) w ith chassis
handles attached
• Depth: 56 .9 cm (22.4 in) from front panel to rear p anel, 62.2 cm (24.5 in) overall
Weight
31 kg (68 lbs)
Input power
Power 100- 240 VAC, 47-63 Hz , auto-selecting 9.0A at 100 VAC
Environmen tal temperature
0-40° Celsius
Environmental humidity
0-95% nonco ndensing
Warranty Full three year parts and labor standard, extended warranty and support available.
HDMI
• per HDMI 1.4a specification
• on HD MI connector (Type A )
• formats up to 2,560x1,600@60 and 3,840x1,200@60 (30 bits)
• 4K/UHD S upported:
- 3 ,840x2,160/23.98/24/25/29.97/30 input v ia 1x HDMI, 2x HDMI (L and R half) or 4x
HDMI ( quadrants)
- 3,840x2,160/50/59.94/60 input via 2x HDMI ( L and R half) or 4x HDMI (quadrants)
- 4 ,096x2,160/23.98/24/25/29.97/30 input v ia 1x HDMI, 2x HDMI (L and R half) or 4x
HDMI ( quadrants)
- 4,096x2,160/50/59.94/60 input via 2x HDMI ( L and R half) or 4x HDMI (quadrants)
• EDID v ersion 1.3 c ompatible
• HDCP version 1.4 compatible
Display port
• per Displayport 1.1a specification
• on D isplayport connector
• formats up to 2,560x1,600@60 and 3,840x1,200@60 (30 bits)
• 4K/UHD S upported:
- 3,840x2,160/23.98/24/25/29.97/30 via 1x DP, 2x DP (L and R half) or 4x DP (quad-
rants)
- 3,840x2,160/50/59.94/60 via 2x DP (L and R half) or 4x DP (quadrants)
- 4,096x2,160/23.98/24/25/29.97/30 via 1x DP, 2x DP (L and R half) or 4x DP (quad-
rants)
- 4,096x2,160/50/59.94/60 via 2x DP (L and R half) or 4x DP (quadrants)
- 4,096x2,400/23.98/24/25/29.97/30/50/59.94/60 via 2x DP (L and R half) or 4x DP
(quadrants)
• EDID v ersion 1.3 c ompatible
• HDCP version 1.4 compatible
DVI
• DVI 1.0 specification
• DVI Digital video on DVI-I connector
• All single-link DVI formats up to 165 MHz
• All dual-link DVI formats up to 330 MH z
• Maximum H Ac tive: 4,096, Maxim um V Active: 3,072
• 4K/UHD S upported:
- 3,840x2,160/23.98/24/25/29.97/30 input via 1x DVI-DL, 2x DVI-SL (L and R half) or
4x DV I-SL (quadrants)
- 3,840x2,160/50/59.94/60 input via 2x DVI-DL (L and R half) or 4x DVI-SL (quad-
rants)
- 4,096x2,160/23.98/24/25/29.97/30 input via 2x D VI-SL ( L and R half) or 4x DV I-SL
(quadrants)
- 4,096x2,160/50/59.94/60 input via 2x DVI-DL (L and R half) or 4x DVI-SL (quad-
rants)
- 4,096x2,400/23.98/24/25/29.97/30 input via 2x D VI-SL ( L and R half) or 4x DV I-SL
(quadrants)
- 4 ,096x2,400/50/59.94/60 input via 2x DVI-DL (L & R half) or 4x DV I-SL (quadrants)
286 R5905948 E2 12/12/2014
