4. Hardware orientation
4. HARDWARE ORIENTATION
About this chap ter
This cha pter explains the E2 hardwa re in detail.
Overview
• Front pane l
• Rear panel
• 6G SDI Input Card
• Dual Link DVI Input Card
• HDMI/DisplayPort Input Card
• HDMI Output Card
• 6G SDI O utput Ca rd
• Expansion link card
R5905948 E2 12/12/2014
