7. System Setup
7.14 Configuration Menu > Add S creen Destinations & Layers
General
In this procedure, you will Add S creen Destinations from the de fined outputs.
Prerequisite
• Ensure that you are familiar with the Configuration Menu. For details on this m enu, pleas e refer to chapter "Configuration
Menu", page 76
If more than one Destination is utilized, repeat the below steps u ntil all Destinations are a dded .
Add Screen Destinations
1. Click on the Destination tabtodefine destinations for the defined outputs.
2. From the diagram area click on the output that you want to be part of the destination.
3. Click o n the +Add Screen Destination blue button t o assign the output to the screen destination .
4. When the de stination is created a box appears next to the E2 diagram.
5. If the more than outputs are part of the destination drag and drop these outputs into the destination bo x. You will observe that
the destination size automatically updates as new outputs are added to the destination.
Add Layers to Destinations
Click o n the Adjust tab that is located on the top.
1. Under the Assign su b-menu click on the +Assign Layer to Destination blue button.
2. Click on this button as many times is required t o add the layers you are assigning to the destination. Obs erve the number of
layers indicated in the Layer box is incremented every time the add button is pressed.
3. If y ou ne ed to delete layers, click on the Blue button Delete layers.
(Optional) Edit the Name
1. Double click on “Destination1” in the Name list to edit the name.
2. When the area turns blue, click the eraser icon to clear the field.
3. Type a new name and hit enter when done.
(Optional) Adjust Destination Parameters
Click on the “Adjust” tab that is located on the top. From this menu you can adjust:
1. Edit the nam e.
2. Select Format v alue, color space and connector type.
3. Enable Tes t Patterns with ras ter box and enable diagonal m otion.
4. Define the Area of interest (AOI).
5. Perform color adjustments.
6. Read the timing parameters associated with the selected format.
7. Select SD I type and SMPT E standards.
8. Adjust data Doubling par ameters.
9. Adjust feathering parameters.
(Optional) Delete Destinations
1. Click on the blue button Delete Destination(s).
2. From the Name list click on the “x” s pace next to the output(s) y ou wish to delete.
3. Hit the red button Delete Destination(s) button. All of the selected Destination(s) will be removed from the list.
R5905948 E2 12/12/2014
171
