7. System Setup
7.12 Configuration M enu > Add Input s
General
In this procedure, you will add Inputs to the system .
Prerequisite
• Ensure that you are familiar with the Configuration Menu. For details on this m enu, pleas e refer to chapter "Configuration
Menu", page 76
If more than one Input is utilized, repeat the below st eps until all Inputs are added and adjusted.
Add Input
1. Click on the Input tab to select the inputs that will be defined.
2. Click on the +Add Input blue button to enter the Add mode.
3. Click on the c onnector that the input signal is c onnected to define it as an input.
4. Click on t he Done Adding button to exit the Add mode.
(Optional) Edit the Name
1. Double click on default nam e in the Name list to edit the nam e.
2. When the area turns blue, click the eraser icon to clear the field.
3. Type a new name.
(Optional) Adjust Input Parameters
Click on the Adjust tab that is located on the top. From this m enu you can ad just:
1. Select Format value, color space and connector type. Default value is 1920x1080p @ 59.94.
2. Select EDID format (for DVI, HDMI and Display Port inputs).
3. Select HDCP mode (for DV I, HDM I and Dis playPort inputs).
4. Select color space, capacity and type (for SDI inputs).
5. Perform color adjustments.
6. Read all timing param eters asso ciated with the selec ted forma t.
(Optional) Auto create Inputs
If the Auto create Inputs is pressed, then the s oftware will add all unas signed inputs to the input list and num ber them sequentially.
This button is a shortcut for systems utilizing a large number of inputs.
(Optional) Delete Inputs
1. Click on the blue button Delete Input(s).
2. From the Name list click on the “x” space next to the Input(s) you w ish to delete.
3. Hit the red button Delete Input(s) button. All of the selected Inputs will be removed from the list.
R5905948 E2 12/12/2014
169
