6. GUI orientation
6.6 Controls
General
Edit box
Edit box is used to edit the values or names.
Image 6-2
Properties:
By double clicking, the background ch anges to a dark blue color indicating that modications can be made.
The cu rsor is placed on the last character.
The eraser button allows deletion of all the c haracters in the edit box.
Slider box
The slider allows modication of the value with slider.
Image 6-3
Properties:
Slide the cursor to modify the value.
The value can also modie d by clicking the + or symbols .
Drop-down menu
Drop-down menu allows the user to choose one value from a list.
Inactive drop-down:
Image 6-4
Active drop-down:
Image 6-5
Properties:
When clicking o n the + symbol, a drop d own menu ap pears with the available c hoices.
By typing in the space next to the magnifying glass all of the available num bers that match the typed text appear, simplifying
the search effort.
R5905948 E2 12/12/2014
75
