4. Hardware orientation
4.6 HDMI Ou tput Card
General
The HDM I Output Card has four 19–pin HDMI connectors wh ich can provide a HDMI video signal.
The gure below illustrates the HDMI output card’s rear panel connectors:
Image 4-8
HDMI Output Card Rear Panel
1 HDMI c onnector HDM I 1
2 HDMI c onnector HDM I 2
3 HDMI c onnector HDM I 3
4 HDMI c onnector HDM I 4
Features
Default slot(s): 11, 12, 14
Provide up to 4 independent signals
4x 19–pin HDMI connector (Typ e A)
The two c onnectors support s ingle link s ignals up-to 300MHz .
Speci ca tions
HDMI per 1.4a Specicatio n
Supported format:
- formats up to 2,560x1,600@ 60 and 3,840x1,200@60 (30 bits)
- 4K/UHD Supported:
o
3,840x2,160/ 23.98/24/25/29.97/30 input via 1x HDMI, 2x HDM I ( L and R half) or 4x H DMI (quadrants)
o
3,840x2,160/ 50/59.94/60 input via 2x HDMI (L and R half) or 4x HDMI (quadrants)
o
4,096x2,160/ 23.98/24/25/29.97/30 input via 1x HDMI, 2x HDM I ( L and R half) or 4x H DMI (quadrants)
o
4,096x2,160/ 50/59.94/60 input v ia 2x HD
MI (L and R ha lf) or 4x HDMI (quadrants)
- EDID version 1.3 compatible
- HDCP version 1.4 c ompatible
R5905948 E2 12/12/2014
41
