7. System Setup
7.16 Configuration Menu > A dd MVR Out puts
General
In this procedure, y ou will add MV R Outputs to the system.
Prerequisite
• Ensure that you are familiar with the Configuration Menu. For details on this m enu, pleas e refer to chapter "Configuration
Menu", page 76
If more t han one Ou tput is utilized, repeat the below st eps until all outputs are added and adjusted .
Add MVR Output
1. Click on the MRV tab to select the outputs that will be defined.
2. Click on the +Add MVR Output blue button to enter the Add m ode.
3. Click on the c onnector that the input signal is connected to de fine it as an output.
4. Click on t he Done Adding button to exit the Add mode.
(Optional) Edit the Name
1. Double click on default nam e in the Name list to edit the nam e.
2. When the area turns blue, click the eraser icon to clear the field.
3. Type a new name and hit enter when done.
(Optional) Adjust Output Parameters
Click on the “Adjust” tab that is located on the top. From this menu you can adjust:
1. Edit the nam e.
2. Select Format v alue, color space and connector type.
3. Enable Tes t Patterns with ras ter box and enable diagonal m otion.
4. Define the Area of interest (AOI).
5. Perform color adjustments.
6. Read the timing parameters associated with the selected format.
7. Adjust HDM I parameters.
(Optional) Auto create MVR Outputs
If the Auto create MVR Outputs is pressed, then the software will add a ll unassigned outputs to the output list and number them
sequentially.
(Optional) Delete Outputs
1. Click on the blue butto n Delete MRV O utput(s).
2. From the Name list click on the “x” spa ce next to the Output(s) you wish to delete.
3. Hit the red b utton D elete Outpu t(s) button. All of the selected Outputs w ill be removed from the list.
