3. General
3.2 F eatures
Inputs
8x Input card s lots supporting up to 4K resolution per slot.
Each c ard slot will accomm odate either 4x HD inputs, 2x 2,560 x 1,600 inputs, or 1x 4K input.
Card type Connector Type
HDMI/DisplayPort input card 2x HDMI 1.4 connectors
2x DisplayPort 1.1 connectors
Dual Link DVI input card 2x Dual Link DVI-D connec tors
6G SDI input c ard 4x B N C connector supporting 6G SDI
Genlock input 2x B NC connec tor (Input and loop output)
Supports B lack burst and trilevel analog s ignals
E2 ships with the following input cards:
•2x6GSDIcards
•2xDVIcards
• 4x HDM I/DP cards
Outputs
3x O utput Card slots for PG M and A ux outputs supporting up to 4K resolution per slot.
1x M ulti-viewer card slot.
Card type Connector Type
HDMI output card 4x HDMI 1.4
6G SDI output card 4x B NC connector s upporting 6G SD I
HDMI Multi-viewer card 4x HDMI 1.4 connectors
E2 ships with the following input cards:
• 14 O utputs via 4 Output cards:
- Up to 3 x 4K Outputs - each Output card s upports up to 4K@ 60 out
- 4 x SD/HD/3G SDI (6G ready)
- 8 x HDMI 1.4 (297 Mpix/sec max)
- 2 x HDMI 1.4 for Multiviewer (297 Mpix/sec max)
• Eight (8) Program O utputs configurable as single screens or tiled/blended wides creens
-Configurable from 8 x 2,048 x 1x200@60 max to 2 x 4,096 x 2,400@60 m ax
User interface
User interface
Details
Event Master Software GUI based configuration and control application
Cross platform (Mac/W indows)
Event Master Console (available 2015) Dedicated hardware panel specifically designed to suppor t the
E2
API for custom User interface programm ing
Allows use r to create custom control programs
Processing and latency
• 12 bits/color
•36bits/pixel
• 1 frame processing latency for progressive sources
PIP layers (per chassis)
Freely assignable PiP lay ers seam less ly transition bet
ween sources
• 2K m ode: 8x seamless P iP or key overlay
• DL mode: 4x seam less PiP or key ov erlay
• 4K m ode: 2x seamless P iP or key overlay
R5905948 E2 12/12/2014
15
