7. System Setup
7. SYSTEM SETU P
About this chap ter
This chapter outlines procedures for setting up and c onfigur ing the E2 product.
CAUTION: Before starting t o set up your E 2 system , please ensure that y ou are familiar with front panel men us
and EM GUI s oftware.
Overview
• Setup Prerequisites
• System s etup sequence
• Power up and Status check
• Return to factory de fault
• Communication setup
• Restoring the system
• User preference setup
• Saving the s etup
• Backing up the system
•Configuration Menu > Initial S etup
•Configuration Menu > Add Background(s)
•Configuration Menu > Add Inputs
•Configuration Menu > Add O utputs
•Configuration M enu > A dd Screen Destinations & L ayers
•Configuration Menu > Add Aux Destinations
•Configuration Menu > Ad d MVR Outputs
• Programming M enu > Select T humbna ils for Backg rounds
• Programming M enu > Select Thumbnails for Inputs
• Programming M enu > C reate Sources from Inputs
• Programming Menu > Drop back grounds into S creen D estinations
• Programming Menu > D rop Layers into Screen Destinations & Sources into layers
• Programming M enu > Drop Inputs to Aux Destinations
• Multiviewer M enu > Drop Inputs, Ba ckgrounds and Destinations
R5905948 E2 12/12/2014
