7. System Setup
7.19 Programming Menu > Create Sources from Inputs
General
In this procedure, you will create sources from the Input sources.
Prerequisite
• Ensure that you are familiar with the Programming M enu. F or details on this menu, please refer to chapter "Programming
Menu", page 105.
When an Input is created, the software copies the Input to a source. More sources c an b e created b y following
the steps be lo w.
(Optional) Create additional sources
1. Click on t he “Input” tab on the t op of the left hand side.
2. Click on the List icon.
Image 7-5
3. Click on the arrow next the Input name.
4. To add m ore sources click on the copy icon.
Image 7-6
(Optional) Rename the Source name
1. Click on t he “Input” tab on the t op of the left hand side.
2. Click on the List icon.
3. Click on the arrow next the Input name.
4. Click on the Source name the you wish to rename.
5. Type the n ew name in the blue box.
176
R5905948 E2 12/12/2014
