A. Specifications
• EDID v ersion 1.3 c ompatible
• HDCP version 1.4 compatible
SDI
• SD/HD/3G SDI (6G ready) on B NC c onnector
• Formats:
- SD Formats: SD-SDI per S MP TE 259M-C (NTSC /PAL resolution)
- HD Formats: HD-SDI per SMPT E 274M, 296M, 2048
- 3G Formats: 3G-SDI per S MP TE 424M , Barcolink
• 6G Ready (via future firmware upgr ade)
• 4K/UHD S upported:
- 3,840x2,160/23.98/24/25/29.97/30 input via 4x HD-SDI (quadrants)
- 3,840x2,160/50/59.94/60 input via 4x 3G-SDI (quadrants)
- 4,096x2,160/23.98/24/25/29.97/30 input via 4x HD-SDI (quadrants)
- 4,096x2,160/50/59.94/60 input via 4x 3G-SDI (quadrants)
HDMI
• per HDMI 1.4a specification
• formats up to 2,560x1,600@60 and 3,840x1,200@60 (30 bits)
• 4K/UHD S upported:
- 3 ,840x2,160/23.98/24/25/29.97/30 input v ia 1x HDMI, 2x HDMI (L and R half) or 4x
HDMI ( quadrants)
- 3,840x2,160/50/59.94/60 input via 2x HDMI (L and R half);or 4x HDMI (quadrants)
- 4 ,096x2,160/23.98/24/25/29.97/30 input v ia 1x HDMI, 2x HDMI (L and R half) or 4x
HDMI ( quadrants)
- 4,096x2,160/50/59.94/60 input via 2x HDMI (L and R half);or 4x HDMI (quadrants)
• EDID v ersion 1.3 c ompatible
• HDCP version 1.4 compatible
SDI
• SD/HD/3G SDI (6G ready) on B NC c onnector
• Formats:
- SD Formats: SD-SDI per S MP TE 259M-C (NTSC /PAL resolution)
- HD Formats: HD-SDI per SMPT E 274M, 296M, 2048
- 3G Formats: 3G-SDI per S MP TE 424M , Barcolink
• 6G Ready (via future firmware upgr ade)
• 4K/UHD S upported:
- 3,840x2,160/23.98/24/25/29.97/30 input via 4x HD-SDI (quadrants)
- 3,840x2,160/50/59.94/60 input via 4x 3G-SDI (quadrants)
- 4,096x2,160/23.98/24/25/29.97/30 input via 4x HD-SDI (quadrants)
- 4,096x2,160/50/59.94/60 input via 4x 3G-SDI (quadrants)
R5905948 E2 12/12/2014 287

Barco E2 Specifications

General

4K Support	Yes
Genlock	Yes
HDCP Support	Yes
Input Connectors	HDMI, DisplayPort, SDI
Output Connectors	HDMI, DisplayPort, SDI
Maximum Resolution	4K/UHD at 60Hz
Redundancy	Optional
Control	Web UI
