Barco E2 User Manual

10. Maintenance
Overview
• E2 unit Overview
• Process Overview
• Spare Parts Serviceable by all users
• Rear I/O and Link Cards
• Rear I/O, VPU and Link card H eatsink Fan
• Front Cover Assem bly
• Front B rackets
• EMI Filter
•3RUFanTray
•1RUFanTray
• VPU Card(s)
• Front Panel Knob
• Front Panel Mount
• Front Panel Board
• VFD Display A ssembly
• VFD Display Filter
• Bottom Panel
• Solid-State Memory
•SystemBattery
• CPU Module
• Power Supply
• System-Power Board
• Genlock Assembly
• USB Cable
• USB Extension Cable
• VFD Cable
• Keyboard Cable
• Genlock Cable
• Ethernet Cable
•3RUFanCable
•1RUFanCable
• Rear Rack E ars
• Front Rac k-Ears
•TopCover
•TopCardGuide
• Motherboard F an
214
R5905948 E2 12/12/2014

Barco E2 Specifications

General

4K Support	Yes
Genlock	Yes
HDCP Support	Yes
Input Connectors	HDMI, DisplayPort, SDI
Output Connectors	HDMI, DisplayPort, SDI
Maximum Resolution	4K/UHD at 60Hz
Redundancy	Optional
Control	Web UI
